Lincoln MKZ II (2012-2016) passenger seat position sensor Wiring diagrams
This page contains all the electrical diagrams for the component. passenger seat position sensor, in which he is found in the car Lincoln MKZ II (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger seat position sensor (1 of 2)
AUTO DIMMING INTERIOR MIRROR
BLK ORG/ WIRE
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL MODULE
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT SEAT RIGHT CLIMATE ACTIVE CONTROL MOTION MODULE CONTROL (SCME) PUMP
FUSION
GLOVE COMPARTMENT LAMP
HEADLAMP SWITCH
LATE PRODUCTION
LEFT VANITY OVERHEAD MIRROR CONSOLE LAMP
MKZ W/ PANORAMIC ROOF
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PANORAMIC ROOF OPENING PANEL PRIMARY MOTOR
PANORAMIC ROOF OPENING PANEL SECONDARY MOTOR
PANORAMIC ROOF OPENING PANEL SHIELD MOTOR
PASSENGER ACTIVE MOTION SEAT MODULE PASSENGER (SCMG) DOOR MODULE
PASSENGER SAFETY BELT BUCKLE
PASSENGER SEAT POSITION SENSOR
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
RAIN SENSOR MODULE
RAIN SENSOR MODULE) (MKZ) (FUSION)
RIGHT EXTERIOR MIRROR
RIGHT FRONT SEAT BACKREST HEATER
RIGHT REAR DOOR MODULE
RIGHT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
RIGHT VANITY MIRROR LAMP
SECOND ROW INTERIOR LAMP
SELECTOR LEVEL ASSEMBLY
SPLICE BLOCK 14 (TOP OF RIGHT "A" PILLAR)
WHT WIRE
Go to component -> Ground distribution circuit, hybrid (3 of 5) -> PASSENGER SEAT POSITION SENSOR
Wiring diagram passenger seat position sensor (2 of 2)
BLK WIRE
BLK/ BLU WIRE
BLK/ GRY WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
CENTRAL UNLOCK RELAY
CHILD LOCK RELAY
DECKLID/ LIFTGATE RELAY
DOUBLE/ CENTRAL AUX LOCK LOCK RELAY RELAY
DRIVER ACTIVE MOTION SEAT MODULE (SCMG)
DRIVER DOOR MODULE
DRIVER SIDE FRONT SEAT CONTROL SWITCH
DRIVER/ FUEL FLAP UNLOCK RELAY
EARLY PRODUCTION
FUEL PUMP FUEL PUMP CONTROL CONTROL MODULE MODULE SHIELD
FUEL PUMP PUMP (FP) ASSEMBLY DRIVER SEAT SHIELD MODULE (DSM)
FUSION
LEFT "C" PILLAR)
LEFT ACTIVE MOTION CONTROL PUMP
LEFT EXTERIOR MIRROR
LEFT FRONT DOOR MAP POCKET LAMP
LEFT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
LEFT FRONT REAR SEAT HEATED BACKREST SEAT HEATER MODULE
LEFT LOCK STATUS LED
LEFT REAR DOOR MODULE (RDM)
LEFT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
LEFT REAR SEAT CUSHION HEATER MAT
LEFT RIGHT VANITY VANITY MIRROR MIRROR LAMP LAMP
MICRO -
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
OVERHEAD CONSOLE
PASSENGER SAFETY BELT BUCKLE
PASSENGER SEAT POSITION SENSOR
RADIO TRANSCEIVER MODULE (RTM)
REAR RIGHT SEAT REAR SEAT HEATED CUSHION SEAT HEATER MAT SWITCH
SECOND ROW INTERIOR LAMP
W/ 10-WAY DRIVER POWER SEAT W/O MEMORY W/ 10-WAY DRIVER POWER SEAT W/ MEMORY
WINDOW
Go to component -> Ground distribution circuit, hybrid (5 of 5) -> PASSENGER SEAT POSITION SENSOR
