Lincoln MKZ II (2012-2016) pass frt cr sn rtn pass frt cr sn feed drvr frt cr sn feed drvr frt cr sn rtn Wiring diagrams

AMBER IND BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CASE GND CLOCK SPRING (BEHIND STEERING WHEEL ASSEMBLY) DRIVER AIR BAG (IN STEERING WHEEL) DRIVER FRONT DOOR SIDE IMPACT SENSOR (CENTER OF LEFT FRONT DOOR) DRIVER SIDE AIR BAG (OUTER EDGE OF DRIVER SEAT BACK) DRIVER SIDE AIR CURTAIN (TOP OF DRIVER SIDE "C" PILLAR) DRIVER TRACK POS PASS TRACK POS DRVR AIR BAG 2 RTN DRVR AIR BAG 2 FEED DRVR CURTAIN FEED DRVR CURTAIN RTN ENS FUSE 35 FUSE 19 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HOT IN RUN OR START HOT IN RUN OR START BODY MICRO CONTROL MODULE (LEFT END OF DASH) FUSE 22 LEFT FRONT IMPACT SEVERITY SENSOR (LEFT FRONT OF ENGINE COMPT) NCA WIRE PAD IND PASS CURTAIN FEED PASS CURTAIN RTN PASS FRT CR SN RTN PASS FRT CR SN FEED DRVR FRT CR SN FEED DRVR FRT CR SN RTN PASSENGER FRONT DOOR SIDE IMPACT SENSOR (CENTER OF PASSENGER FRONT DOOR) PASSENGER SIDE AIR BAG (OUTER EDGE OF PASSENGER SEAT BACK) PASSENGER SIDE AIR CURTAIN (TOP OF PASSENGER SIDE "C" PILLAR) RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT OF ENGINE COMPT) SHORTING BAR SHORTING BAR IS STAGE 1 STAGE 2 VIO WIRE VIO/ GRY WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE VPWR PAD INDICATOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/ ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

AMBER IND BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CASE GND CLOCK SPRING (BEHIND STEERING WHEEL ASSEMBLY) DRIVER AIR BAG (IN STEERING WHEEL) DRIVER FRONT DOOR SIDE IMPACT SENSOR (CENTER OF DRIVER FRONT DOOR) DRIVER SIDE AIR CURTAIN (TOP OF PASSENGER SIDE "C" PILLAR) DRIVER TRACK POS PASS TRACK POS DRVR AIR BAG 2 RTN DRVR AIR BAG 2 FEED DRVR CANOPY FEED DRVR CANOPY RTN ENS FUSE 35 FUSE 19 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEV PHEV HOT IN RUN OR START HOT IN RUN OR START BODY CONTROL MODULE (BCM) FUSE 22 LEFT FRONT SIDE AIR BAG MODULE NCA WIRE PAD IND PASS CANOPY FEED PASS CANOPY RTN PASS FRT CR SN RTN PASS FRT CR SN FEED DRVR FRT CR SN FEED DRVR FRT CR SN RTN PASSENGER FRONT DOOR SIDE IMPACT SENSOR (CENTER OF PASSENGER FRONT DOOR) RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT FRONT IMPACT SEVERITY SENSOR (RIGHT FRONT OF ENGINE COMPT) RIGHT FRONT SIDE AIR BAG MODULE SHORTING BAR SHORTING BAR IS STAGE 1 STAGE 2 VIO WIRE VIO/ GRY WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE VPWR PAD INDICATOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/ ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
