Lincoln MKZ II (2012-2016) panoramic roof opening panel shield wiring diagram
This page shows the only wiring diagram for the component.panoramic roof opening panel shield, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
panoramic roof opening panel shield wiring diagram (1 of 1)
ACCESSORY DELAY RELAY
BATTERY JUNCTION BOX
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CAN (+)
CLOSE
COMPUTER DATA LINES SYSTEM
DISCRETE VSPD (HB)
EXCEPT HYBRID
FUSE 85 FUSE 72
GND TILT GLOBAL SHADE OPEN REV SIG SHADE CLOSE B+ K-BUS
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
HALF BRIDGE
HOT AT ALL TIMES
ID-LOW
IGN/DELAY ACC
K- BUS
M ROOF CLOSE
M ROOF OPEN
M ROOF TILT
MICRO FUSE
MOTOR (EXCEPT HYBRID: REAR OF ROOF) (HYBRID: RIGHT REAR OF PANORAMIC ROOF)
NCA WIRE
OVERHEAD CONSOLE
PANORAMIC ROOF OPENING PANEL ANTI-PINCH SWITCH (REAR OF PANORAMIC ROOF)
PANORAMIC ROOF OPENING PANEL SECONDARY MOTOR
PANORAMIC ROOF OPENING PANEL SHIELD
PINCH SENS
PULSE TRAIN (FET)
REV LPS (FET)
SENS GND
SHADE CLOSE
SHADE OPEN
VEH SPEED
VIO WIRE
VIO/BRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/ORG WIRE
Go to component -> Panoramic roof circuit -> PANORAMIC ROOF OPENING PANEL SHIELD
