Lincoln MKZ II (2012-2016) panoramic driver roof door opening window panel control primary switch motor Wiring diagram
This page shows the only wiring diagram for the component.panoramic driver roof door opening window panel control primary switch motor, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panoramic driver roof door opening window panel control primary switch motor (1 of 1)
ACCESSORY DELAY RELAY
AMBIENT LTG (FET)
AUTO DIMMING INTERIOR MIRROR
BATT CURR
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CENTRAL LOCK RELAY
CENTRAL UNLOCK RELAY
CHILD LOCK RELAY
CIRCUIT BREAKER 38 FUSE 31
DATA LINK
DECKLID/ LIFT GATE RELAY
DOOR LOCK LED STATUS (FET)
DOUBLE/ AUX LOCK RELAY
DRIVER SIDE CENTER REGISTER AIR DISCHARGE TEMPERATURE SENSOR
DRIVER/ FUEL FLAP UNLOCK RELAY
FD (HB)
FROM FUSE 18 (DIAGRAM 4 OF 7)
FUEL PUMP ON (FET)
FUSE 16
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 24
FUSE 3
FUSE 34
FUSE 35
FUSE 36
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE (HCM)
HEATED ALL WHEEL STEERING DRIVE (AWD) WHEEL RELAY MODULE MODULE
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
KEYPAD ILLUM (FET)
MICRO -
MICRO FUSE 15
MKZ FUSION
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
ORG/ WIRE
PANORAMIC DRIVER ROOF DOOR OPENING WINDOW PANEL CONTROL PRIMARY SWITCH MOTOR
PASSENGER SELECTOR AIR BAG LEVER DEACTIVATION ASSEMBLY (PAD) INDICATOR (FUSION)
REAR HEATED SEAT MODULE
REAR WINDOW BLIND MODULE (MKZ)
RED WIRE
RESTRAINTS CONTROL MODULE (RCM)
ROOF OPENING PANEL MODULE
RUN/START RELAY
TO DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER (DIAGRAM 7 OF 7)
TO START BUTTON (FET) (DIAGRAM 7 OF 7)
VEHICLE DYNAMICS MODULE (VDM)
VIO WIRE
W/ PANORAMIC
W/O PANORAMIC
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (5 of 7) -> PANORAMIC DRIVER ROOF DOOR OPENING WINDOW PANEL CONTROL PRIMARY SWITCH MOTOR
