Lincoln MKZ II (2012-2016) ect frp Wiring diagram
This page shows the only wiring diagram for the component.ect frp, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect frp (1 of 1)
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ECT FRP
GRN WIRE
GRN/ YEL WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
KNOCK
LPC
NEAR BREAKOUT TO COIL ON PLUG 1)
OIL PRESSURE SWITCH (OIL FILTER HOUSING)
OSS +
OSS/TR GND
OSS/TR VPWR
PM HTR TCWRVS
POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE)
SIGRTN
SSA
SSB
SSC
SSD
SSD ETCRTN TSS/OSS/ TR GND MAP
SSE
SSE TCBY
TCC
TCC SSB CHT
TFT
TFT SIG RTN
TR-P
TRS
TSPC
TSS
TSS/GND
TSS/OSS TR VPWR
TSS/VPWR
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VREF ETCREF VREF OPS TR-P CKP OSS
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 6) -> ECT FRP
