Lincoln MKZ II (2012-2016) cpc lin hfc lfc vacc accr wiring diagram
This page shows the only wiring diagram for the component.cpc lin hfc lfc vacc accr, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
cpc lin hfc lfc vacc accr wiring diagram (1 of 1)
1.6L TURBO 1.5L TURBO 2.0L TURBO 2.5L 3.7L
3.7L
AAT ACPT VREF SIG RTN
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER
AMBIENT AIR TEMPERATURE SENSOR (BEHIND RIGHT END OF FRONT GRILLE)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR)
COOLING FAN MOTOR 2
CPC LIN HFC LFC VACC ACCR
ECT CHT SIG RTN 39 49 39 49
ENGINE CONTROLS SYSTEM
FAN CONTROL (FC) RELAY
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
HIGH FAN CONTROL (HFC) RELAY
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LOW FAN CONTROL (LFC) RELAY
ORG/ WIRE
POWERTRAIN CONTROL MODULE
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, except hybrid (3 of 3) -> CPC LIN HFC LFC VACC ACCR
