Lincoln MKZ II (2012-2016) breakout to coil on plug 3) Wiring diagram
This page shows the only wiring diagram for the component.breakout to coil on plug 3), which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram breakout to coil on plug 3) (1 of 1)
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BREAKOUT TO COIL ON PLUG 3)
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LPC
NCA WIRE
OSS +
SSA
SSB
SSC
SSD
SSE
TCC
TFT
TFT SIG RTN
TR 1
TR 2
TR 3
TR 4
TR GND
TRS
TSPC
TSS
TSS/OSS GND
UNIVERSAL HEATED OXYGEN SENSOR 11 (RIGHT EXHAUST MANIFOLD)
UNIVERSAL HEATED OXYGEN SENSOR 21
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.7l (4 of 6) -> BREAKOUT TO COIL ON PLUG 3)
