Lincoln MKZ II (2012-2016) (body main wiring harness, in breakout to Wiring diagram

1 2 3 4 5 6 VPWR HS 2 CAN + HS 2 CAN - GND BTS VREF BTS SIG 1 2 3 6 5 BTS SIG BTS VREF GND GND BUCKLE SW BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BTS SIG BTS VREF BUCKLE SW COMPUTER DATA LINES SYSTEM DRIVER SAFETY BELT BUCKLE (INTEGRAL TO DRIVER SEAT BELT BUCKLE ASSEMBLY) DRIVER SEAT POSITION SENSOR (UNDER DRIVER SEAT) EARLY PRODUCTION ENS GRN/BLU WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE GRY/YEL WIRE INSTRUMENT PANEL CLUSTER (IPC) LATE PRODUCTION EARLY PRODUCTION LEFT SECOND ROW SAFETY BELT INFLATOR (IN LEFT SECOND ROW SEAT BELT) MODULE (RCM) NCA WIRE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) (UNDER PASSENGER'S SEAT) PASSENGER SAFETY BELT BUCKLE (INTEGRAL TO PASSENGER SEAT BELT BUCKLE ASSEMBLY) PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF RIGHT "B" PILLAR) PASSENGER SEAT POSITION SENSOR (UNDER PASSENGER SEAT) RIGHT SECOND ROW SAFETY BELT INFLATOR (IN RIGHT SECOND ROW SEAT BELT) SECOND ROW SAFETY BELT BUCKLE ASSEMBLY (INTEGRAL TO SEAT BELT BUCKLE ASSEMBLIES) SHORTING BAR UNDER DRIVER'S SEAT) (LATE PRODUCTION: UNDER PASSENGER'S SEAT) VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE
