Lincoln MKZ II (2012-2016) active hood grille ajar shutter switch Wiring diagram
This page shows the only wiring diagram for the component.active hood grille ajar shutter switch, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram active hood grille ajar shutter switch (1 of 1)
1.5L TURBO, 1.6L, 2.0L, 2.0L TURBO
ACTIVE HOOD GRILLE AJAR SHUTTER SWITCH
AIR CONDITIONING LOW BRAKE (A/C) FLUID WARNING COMPRESSOR INDICATOR SWITCH
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLOWER MOTOR CONTROL MODULE
BLOWER MOTOR DIODE RELAY
CABIN TRANSMISSION HEATER FLUID PUMP COOLANT PUMP
COIL ON COIL ON PLUG PLUG (COP) 1 (COP) 2
COIL ON COIL ON PLUG PLUG (COP) 3 (COP) 4
DISPLAY
FAN CONTROL (FC) RELAY
FRONT HAZARD LUGGAGE FLASHER COMPARTMENT SWITCH OPEN/CLOSE SWITCH
FUEL PUMP ASSEMBLY SHIELD
FUEL PUMP CONTROL MODULE (FUEL TANK GAUGE, SENDER WIRING HARNESS, NEAR
FUSION
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
GRY WIRE
HEADLAMP SWITCH
HORN
LEFT "C" PILLAR)
LEFT FRONT WINDSHIELD WIPER MOTOR
MULTI- CONTOUR SEAT RELAY
NCA WIRE
POWER STEERING CONTROL MODULE (PSCM)
PROXIMITY WARNING RADAR UNIT
STOPLAMP SWITCH
TRANSMISSION RANGE CONTROL MODULE (TRCM)
W/O TOUCH SCREEN
Go to component -> Ground distribution circuit, except hybrid (1 of 5) -> ACTIVE HOOD GRILLE AJAR SHUTTER SWITCH
