Lincoln MKZ II (2012-2016) aat hfc fpc canv injpwrm Wiring diagram

AAT HFC FPC CANV INJPWRM ACCR BPP GENMON ACPT FPM AIR CONDITIONING PRESSURE TRANSDUCER (RIGHT FRONT OF ENGINE COMPT) AIR CONDITIONING SYSTEM ALL WHEEL DRIVE (AWD) RELAY MODULE (RIGHT SIDE OF LUGGAGE COMPT) AMBIENT AIR TEMPERATURE SENSOR (BEHIND RIGHT END OF FRONT GRILLE) AWDC AWDM BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE MICRO BPS IAT BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DIGITAL FTP VREF VPWR VPWR PWRGND PWRGND FUEL PUMP (FET) FUEL PUMP ON (FET) FUEL TANK PRESSURE (FTP) SENSOR (TOP OF FUEL TANK) FUSE 18 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE HOT AT ALL TIMES HS CAN + HS CAN - IES LFC PCM WAKE MAF SIGRTN ISPR PCM WAKEUP (FET) POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) PWRGND SIGRTN SMC SMCS PCMRC SST+ SST- STARTING/CHARGING SYSTEM TO COIL ON PLUG 3) VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VREF GENCOM AWDC AGS SIGRTN WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
