Lincoln MKZ II (2012-2016) 1 2 3 6 5 bts sig bts vref gnd gnd pass buck sw Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 6 5 bts sig bts vref gnd gnd pass buck sw, which is found in the car Lincoln MKZ II (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 6 5 bts sig bts vref gnd gnd pass buck sw (1 of 1)
1 2 3 4 5 6 RUN/START HS CAN + HS CAN - GND BTS VREF BTS SIG
1 2 3 6 5 BTS SIG BTS VREF GND GND PASS BUCK SW
BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BUCKLE SW
COMPUTER DATA LINES SYSTEM
DRIVER SAFETY BELT BUCKLE (INTEGRAL TO DRIVER SEAT BELT BUCKLE ASSEMBLY)
EARLY PRODUCTION
ENS
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT
NCA WIRE
NOT USED
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) (UNDER PASSENGER'S SEAT)
PASSENGER SAFETY BELT BUCKLE (INTEGRAL TO PASSENGER SEAT BELT BUCKLE ASSEMBLY)
PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (BASE OF RIGHT "B" PILLAR)
RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE)
RIGHT
SAFETY BELT INFLATOR (IF EQUIPPED) (IN LEFT SEAT BELT)
SAFETY BELT INFLATOR (IF EQUIPPED) (IN RIGHT SEAT BELT)
SHORTING BAR
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit, except hybrid (3 of 3) -> 1 2 3 6 5 BTS SIG BTS VREF GND GND PASS BUCK SW
