Lincoln MKZ II (2012-2016) 1 2 3 4 5 6 drv batt run/start pass batt lr htr fd gnd rr htr fd Wiring diagram

1 2 3 4 5 6 DRV BATT RUN/START PASS BATT LR HTR FD GND RR HTR FD BACKLIGHTING IND BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (LEFT END OF DASH) BRN WIRE DRV HIGH SW LR SEAT NTC RR HIGH/OFF RR LOW/OFF EXCEPT HYBRID EXCEPT HYBRID HYBRID FUSE 21 FUSE 73 GRN WIRE GRN/BRN WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LEFT HIGH IND LEFT LOW IND LEFT REAR SEAT BACKREST HEATER MAT LEFT REAR SEAT CUSHION HEATER MAT LEFT SW NCA WIRE PASS HIGH SW RR SEAT NTC PASS LOW IND PASS HIGH IND RETURN REAR HEATED SEAT MODULE (UNDER LEFT SECOND ROW SEAT) REAR SEAT HEATER SWITCH RED WIRE RIGHT HIGH IND RIGHT LOW IND RIGHT REAR SEAT BACKREST HEATER MAT RIGHT REAR SEAT CUSHION HEATER MAT RIGHT SW SPLICE BLOCK 12 (UNDER LEFT SECOND ROW SEAT) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
