Lincoln MKZ I facelift (2009-2012) (trunk wire harness near breakout wiring diagram
This page shows the only wiring diagram for the component.(trunk wire harness near breakout, which is found in the car Lincoln MKZ I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(trunk wire harness near breakout wiring diagram (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLU WIRE
BLU/RED WIRE
BRN WIRE
DIODE
EXCEPT 3.5L 3.5L
FLOOR SHIFTER
FROM FUSE 28, SMART JUNCTION BOX (DIAGRAM 2 OF 5)
FROM FUSE 44, SMART JUNCTION BOX (DIAGRAM 2 OF 5)
FROM FUSE 45, SMART JUNCTION BOX (DIAGRAM 2 OF 5)
FROM SMART JUNCTION BOX (DIAGRAM 2 OF 5)
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT HEATED SEAT MODULE
FUSE 29
FUSE 32
FUSE 35
FUSE 36
FUSE 46
GRN WIRE
GRY WIRE
IGNITION SWITCH
INHIBIT
INSTRUMENT PASSENGER CLUSTER AIR BAG DEACTIVATION (PAD) INDICATOR
KEY IN
KEY IN IGNITION
LEFT REAR SIDE OBSTACLE DETECTION (SOD) SENSOR
LOCK
LOGIC
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
OFF
ONE TOUCH INTEGRATED
ORG/ WIRE
PARKING REAR AID VIEW MODULE CAMERA (PAM)
PASSIVE ANTI-THEFT TRANSCEIVER
POWERTRAIN CONTROL MODULE (PCM)
RESTRAINTS CONTROL CONTROL MODULE MODULE (RCM)
RIGHT REAR SIDE OBSTACLE DETECTION (SOD) SENSOR
RUN WIRE
STARTER RELAY
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (3 of 5) -> (TRUNK WIRE HARNESS NEAR BREAKOUT
