Lincoln MKZ I facelift (2009-2012) traction control/ ambient lighting switch Wiring diagrams
This page contains all the electrical diagrams for the component. traction control/ ambient lighting switch, in which he is found in the car Lincoln MKZ I facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram traction control/ ambient lighting switch (1 of 2)
13 46 46 47 BOO BPS
21 5 26 25 18 B+ PWR GND HS CAN- HS CAN+ TRACTION CTL ON/OFF
3.5L 2.5L, 3.0L
42 43 44 45 46 47 RR SENSOR- RR SENSOR+
7 8 TRACTION CTL ON/OFF
9 10 19 20 HS CAN - HS CAN + TC CAN STAT- TC CAN STAT+
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY JUNCTION FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/GRY WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BOO OF DASH) INPUT
BRAKE BOOSTER VACUUM SENSOR (3.0L AWD, 3.5L) (ON BRAKE BOOSTER)
BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH)
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
CONTROL MODULE
EXCEPT MKZ MKZ
FRONT CONTROL INTERFACE MODULE (FCIM) (CENTER OF DASH)
FUSE
FUSE 2
FUSE 26
FUSE 42
GRN WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/ PCM POWER RELAY ENERGIZED
HS CAN + HS CAN -
INSTRUMENT CLUSTER (IC)
IVD PWR
IVD RTN SAS A
LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT HUB ASSEMBLY)
LEFT REAR WHEEL SPEED SENSOR (LEFT REAR HUB ASSEMBLY)
LF SENSOR+ LF SENSOR-
LR SENSOR+ LR SENSOR-
MTR GND
NCA WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT)
RED WIRE
RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE)
RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY)
RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR HUB ASSEMBLY)
RUN/START SAS B
SMART JUNCTION BOX (SJB) (LEFT SIDE
STEERING ANGLE SENSOR MODULE (SASM)
TC CAN STAT + TC CAN STAT -
TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
VAC PWR VAC GND
VAC SIG
VALVE PWR RF SENSOR- RF SENSOR+
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit -> TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
Wiring diagram traction control/ ambient lighting switch (2 of 2)
ACCESSORY DELAY RELAY
AMBIENT LIGHTING MODULE
AMBIENT SELECT SWITCH
AUTO DIMMING INTERIOR MIRROR
BACKLIGHTING (FET)
BLU WIRE
CIRCUIT BREAKER 47
DEMAND LAMP/ BATTERY SAVER RELAY
FROM FRONT CIGAR LIGHTER (DIAGRAM 2 OF 5)
FROM FUSE 21 (DIAGRAM FUSE 22 4 OF 5)
FUSE 10
FUSE 25
FUSE 41
FUSE 5
FUSE 6
FUSE 9
FUSION, MILAN
GRN WIRE
INTERIOR LIGHTING BSI (FET) (FET)
KEYPAD LOGIC ILLUM (FET)
LEFT FRONT TURN LAMP (FET)
LEFT REAR PARK/TURN LAMP (FET)
LEFT REAR TURN LAMP (FET)
MASTER WINDOW CONTROL SWITCH
MASTER WINDOW DRIVER SIDE CONTROL DOOR LOCK SWITCH SWITCH (W/ SMART WINDOW)
MULTIMEDIA REAR VIEW CAMERA INTERIOR MIRROR DISPLAY UNIT MIRROR
OVERHEAD LIGHTING (EARLY PRODUCTION W/ MKZ AMBIENT LIGHTING)
PARK LAMP RELAY
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH (W/ SMART WINDOW)
PUDDLE LAMP (FET)
RIGHT FRONT TURN LAMP (FET)
RIGHT REAR PARK/TURN LAMP (FET)
RIGHT REAR TURN LAMP (FET)
ROOF OPENING PANEL MODULE
ROOF OPENING PANEL SWITCH
TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
W/O SMART WINDOW W/ SMART WINDOW
Go to component -> Power distribution circuit (5 of 5) -> TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
