Lincoln MKZ I facelift (2009-2012) starter diode wiring diagram
This page shows the only wiring diagram for the component.starter diode, which is found in the car Lincoln MKZ I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
starter diode wiring diagram (1 of 1)
ANTI-THEFT SYSTEM POWER DISTRIBUTION SYSTEM
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/RED WIRE
BRN/YEL WIRE
DIMMING CTRL
FRONT FOG LAMP RLY
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
IGN RUN OR ACC SW IGN RUN OR START SW
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM HEADLIGHTS SYSTEM POWER DISTRIBUTION SYSTEM
INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
INTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
KEY IN
LCK
OFF
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM INSTRUMENT CLUSTER SYSTEM
POWER DISTRIBUTION SYSTEM SOUND SYSTEMS
RUN WIRE
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SOUND SYSTEMS
STARTER DIODE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Body control modules circuit (2 of 2) -> STARTER DIODE
