Lincoln MKZ I facelift (2009-2012) pwr window global set ctrl keyless keypad illu sw ctrl puddle lamps rly Wiring diagram
This page shows the only wiring diagram for the component.pwr window global set ctrl keyless keypad illu sw ctrl puddle lamps rly, which is found in the car Lincoln MKZ I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr window global set ctrl keyless keypad illu sw ctrl puddle lamps rly (1 of 1)
ALL LCK/UNLCK RLY GND GND
BATTERY
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DOOR LOCKS SYSTEM
DUAL BATTERY FUSE ASSEMBLY (REAR OF ENGINE)
EXTERIOR LIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
FRONT WIPER CTRL LOW LEVEL BRAKE FLUID SW HOOD AJAR SW
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEADLIGHTS SYSTEM
HORNS SYSTEM EXTERIOR LIGHTS SYSTEM
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT LOW BEAM CTRL
LF TURN LAMP CTRL
LIFTGATE GLASS LCK RLY
MIDI FUSE (WHITE)
MIRRORS, SEATS SYSTEMS
PARK LAMP RLY BATTERY SAVER RLY
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM
POWER WINDOWS, POWER TOPS SYSTEMS DOOR LOCKS SYSTEM EXTERIOR LIGHTS SYSTEM
PWR WINDOW GLOBAL SET CTRL KEYLESS KEYPAD ILLU SW CTRL PUDDLE LAMPS RLY
RED WIRE
RH TURN LAMP CTRL
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SOUND SYSTEMS
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
WIPER/WASHER SYSTEM INSTRUMENT CLUSTER SYSTEM DOOR LOCKS SYSTEM
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Body control modules circuit (1 of 2) -> PWR WINDOW GLOBAL SET CTRL KEYLESS KEYPAD ILLU SW CTRL PUDDLE LAMPS RLY
