Lincoln MKZ I facelift (2009-2012) master window control switch Wiring diagrams
This page contains all the electrical diagrams for the component. master window control switch, in which he is found in the car Lincoln MKZ I facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
master window control switch wiring diagram (1 of 2)
ACCESSORY DELAY RELAY
AMBIENT LIGHTING MODULE
AMBIENT SELECT SWITCH
AUTO DIMMING INTERIOR MIRROR
BACKLIGHTING (FET)
BLU WIRE
CIRCUIT BREAKER 47
DEMAND LAMP/ BATTERY SAVER RELAY
FROM FRONT CIGAR LIGHTER (DIAGRAM 2 OF 5)
FROM FUSE 21 (DIAGRAM FUSE 22 4 OF 5)
FUSE 10
FUSE 25
FUSE 41
FUSE 5
FUSE 6
FUSE 9
FUSION, MILAN
GRN WIRE
INTERIOR LIGHTING BSI (FET) (FET)
KEYPAD LOGIC ILLUM (FET)
LEFT FRONT TURN LAMP (FET)
LEFT REAR PARK/TURN LAMP (FET)
LEFT REAR TURN LAMP (FET)
MASTER WINDOW CONTROL SWITCH
MASTER WINDOW DRIVER SIDE CONTROL DOOR LOCK SWITCH SWITCH (W/ SMART WINDOW)
MULTIMEDIA REAR VIEW CAMERA INTERIOR MIRROR DISPLAY UNIT MIRROR
OVERHEAD LIGHTING (EARLY PRODUCTION W/ MKZ AMBIENT LIGHTING)
PARK LAMP RELAY
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH
PASSENGER SIDE WINDOW CONTROL SWITCH (W/ SMART WINDOW)
PUDDLE LAMP (FET)
RIGHT FRONT TURN LAMP (FET)
RIGHT REAR PARK/TURN LAMP (FET)
RIGHT REAR TURN LAMP (FET)
ROOF OPENING PANEL MODULE
ROOF OPENING PANEL SWITCH
TRACTION CONTROL/ AMBIENT LIGHTING SWITCH
W/O SMART WINDOW W/ SMART WINDOW
Go to component -> Power distribution circuit (5 of 5) -> MASTER WINDOW CONTROL SWITCH
master window control switch wiring diagram (2 of 2)
ACCESSORY DELAY RELAY
AUTO
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CIRCUIT BREAKER 47
DOWN GND
FUSE 17
FUSE 41
GO PWR
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT
LEFT FRONT POWER WINDOW MOTOR (DRIVER'S DOOR)
LEFT REAR
LOCK OUT
LOGIC
MASTER WINDOW CONTROL SWITCH
MICRO -
POWER TOPS SYSTEM
PULSE TRAIN (FET)
PWR DOWN
RED WIRE
RIGHT FRONT
RIGHT FRONT POWER WINDOW MOTOR (FRONT PASSENGER'S DOOR)
RIGHT REAR
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
UP DN
VIO/WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit (1 of 2) -> MASTER WINDOW CONTROL SWITCH
