Lincoln MKZ I facelift (2009-2012) gnd open close auto wiring diagram
This page shows the only wiring diagram for the component.gnd open close auto, which is found in the car Lincoln MKZ I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
gnd open close auto wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 B+ VPWR
ACCESSORY DELAY RELAY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
EXCEPT HYBRID
FUSE 17
FUSE 41
GND OPEN CLOSE AUTO
GO SW RTN
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY FUSE 33 JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
LEFT FRONT POWER WINDOW MOTOR (DRIVER'S DOOR)
LOGIC
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (FRONT PASSENGER'S DOOR)
ROOF OPENING PANEL MODULE (FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO/BRN WIRE
VIO/WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power top/sunroof circuit -> GND OPEN CLOSE AUTO
