Lincoln MKZ I facelift (2009-2012) 9 10 19 20 hs can - hs can + tc can stat- tc can stat+ Wiring diagram

13 46 46 47 BOO BPS 21 5 26 25 18 B+ PWR GND HS CAN- HS CAN+ TRACTION CTL ON/OFF 3.5L 2.5L, 3.0L 42 43 44 45 46 47 RR SENSOR- RR SENSOR+ 7 8 TRACTION CTL ON/OFF 9 10 19 20 HS CAN - HS CAN + TC CAN STAT- TC CAN STAT+ ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY JUNCTION FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/GRY WIRE BLK/VIO WIRE BLU/ORG WIRE BLU/WHT WIRE BOO OF DASH) INPUT BRAKE BOOSTER VACUUM SENSOR (3.0L AWD, 3.5L) (ON BRAKE BOOSTER) BRAKE PEDAL POSITION SWITCH (LEFT SIDE OF DASH) BRN WIRE BRN/GRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM CONTROL MODULE EXCEPT MKZ MKZ FRONT CONTROL INTERFACE MODULE (FCIM) (CENTER OF DASH) FUSE FUSE 2 FUSE 26 FUSE 42 GRN WIRE GRN/ORG WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT W/ PCM POWER RELAY ENERGIZED HS CAN + HS CAN - INSTRUMENT CLUSTER (IC) IVD PWR IVD RTN SAS A LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (LEFT REAR HUB ASSEMBLY) LF SENSOR+ LF SENSOR- LR SENSOR+ LR SENSOR- MTR GND NCA WIRE ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT) RED WIRE RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR HUB ASSEMBLY) RUN/START SAS B SMART JUNCTION BOX (SJB) (LEFT SIDE STEERING ANGLE SENSOR MODULE (SASM) TC CAN STAT + TC CAN STAT - TRACTION CONTROL/ AMBIENT LIGHTING SWITCH VAC PWR VAC GND VAC SIG VALVE PWR RF SENSOR- RF SENSOR+ VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE
