Lincoln MKZ I (2006-2009) reversing lamps switch Wiring diagrams
This page contains all the electrical diagrams for the component. reversing lamps switch, in which he is found in the car Lincoln MKZ I (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram reversing lamps switch (1 of 2)
Go to component -> Back-up lamps circuit, m/t -> REVERSING LAMPS SWITCH
Wiring diagram reversing lamps switch (2 of 2)
6 SPEED TRANSMISSION
ACCESSORY DELAY RELAY
ALL- WHEEL DRIVE CONTROL MODULE
BASE/ AUDIOPHILE AUDIO
BLK WIRE
BOX (SJB) (BASE OF LEFT "A" PILLAR)
BRN WIRE
CIRCUIT BREAKER
DECKLID RELEASE RELAY DRIVER UNLOCK RELAY
DRIVER DOOR MODULE
DRIVER SIDE DOOR LOCK SWITCH (FUSION/ MILAN)
ENGINE COOLING FAN MOTOR
EXTERIOR REAR VIEW MIRROR SWITCH
FROM FUSE 13 SMART JUNCTION BOX (DIAGRAM 1 OF 3)
FROM FUSE 26 SMART JUNCTION BOX (DIAGRAM 3 OF 3)
FROM FUSE 3 SMART JUNCTION BOX (DIAGRAM 2 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM SPLICE
FRONT CIGAR LIGHTER (FUSION/ MILAN)
FRONT CIGAR LIGHTER (MKZ)
FUEL PCM POWER PUMP RELAY DIODE
FUSE 12
FUSE 15
FUSE 16
FUSE 20
FUSE 23
FUSE 26
FUSION, MILAN
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER
LOCK ALL RELAY
LOGIC
MASTER WINDOW ADJUST SWITCH
NCA WIRE
NEAR BREAKOUT TO MASTER WINDOW ADJUST SWITCH)
ORG/ WIRE
PASSENGER SIDE DOOR LOCK SWITCH (FUSION/ MILAN)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE) (EXCEPT 3.5L: NEAR ENGINE BULKHEAD GROMMET)
RED WIRE
REVERSING LAMPS SWITCH
ROOF OPENING PANEL MODULE
SATELLITE RADIO RECEIVER
SMART JUNCTION
THX AUDIO/ NAVIGATION AUDIO UNIT
TO CIGAR LIGHTER (DIAGRAM 3 OF 3)
UNLOCK ALL RELAY
VIO WIRE
WHT WIRE
WIPER BLOWER RUN/PARK RELAY MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> REVERSING LAMPS SWITCH
