Lincoln MKZ I (2006-2009) pass hi led ind Wiring diagram

"A" PILLAR) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE DRIVER HS REQ DRIVER HSHI DRIVER HSLO DRV BATT DRV HEATER FEED DRV HI LED IND DRV HIGH/LOW/OFF DRV LOW LED IND DRV NTC SENSE DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) MODULE FUSE 11 FUSE 28 GRN WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HEATED SEAT MODULE (UNDER SEAT BOTTOM) HOT AT ALL TIMES HOT IN START OR RUN LEFT FRONT SEAT BACK HEATER (IN DRIVER'S LEFT FRONT SEAT CUSHION HEATER (IN SEAT CUSHION) NCA WIRE NTC RETURN ORG/ WIRE PAN) PASS BATT PASS HEATER FEED PASS HI LED IND PASS HIGH/LOW/OFF PASS HS REQ PASS HSHI PASS HSLO PASS LOW LED IND PASS NTC SENSE RED WIRE RIGHT FRONT SEAT BACK HEATER (RIGHT SIDE OF FRONT PASSENGER'S SEAT BACK) RIGHT FRONT SEAT CUSHION HEATER (RIGHT SIDE OF FRONT PASSENGER'S SEAT BOTTOM) RUN/START SEAT BACK) SMART JUNCTION BOX (SJB) (BASE OF LEFT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE
