Lincoln MKZ I (2006-2009) multi-function switch mist off int 1 int 2 int 3 1) 2) wiring diagram

3) 4) 5) FRONT WASH SWITCH INT 4 INT 5 LOW HIGH WASH 6) 7) 8) 9) 10) BLK WIRE BLU WIRE BRN WIRE EARLY PRODUCTION LATE PRODUCTION FRONT WIPER SWITCH FUSE FUSE 1 FUSE 23 FUSE 9 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR ACC LOGIC MFS CODE A MFS H LINE MFS CODE B MFS CODE C MFS W LINE MULTI-FUNCTION SWITCH MIST OFF INT 1 INT 2 INT 3 1) 2) ORG/ WIRE RED WIRE SMART JUNCTION BOX (SJB) SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR) WIPER RUN/PARK COIL VIO WIRE WASHER PUMP RELAY WHT WIRE WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) WIPER MOTOR RELAY WIPER PARK WIPER PARK RELAY WIPER RUN/PARK RELAY YEL WIRE
