Lincoln MKZ I (2006-2009) maf mafrtn iat ftpt injpwrm boo bps Wiring diagram

A/C PRESSURE TRANSDUCER SENSOR (CENTER REAR OF ENGINE COMPT) AIR CONDITIONING SYSTEM APP 1 APP 2 APP 3 APPSREF 2 FTPTREF FPM APPSREF 1 BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/YEL WIRE C VREF SMC PCM CONTROL C-SIGRTN CASE GND PWR GND 1 PWR GND 2 PWR GND 3 COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM COOLING FANS SYSTEM EVAP CANISTER VENT CONTROL SOLENOID (REAR OF VEHICLE CHASSIS) EVAPORATIVE EMISSION (EVAP) CANISTER PURGE VALVE (RIGHT REAR OF ENGINE COMPT) FC-V FUSE FUSE 3 FUSE 42 FUSE 48 FUSE 49 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN HOT IN START OR RUN HS CAN + HS CAN - EVMV IAT IGNITION KAPWR FEPS SCCS SCCSRTN C SIGRTN APPSRTN 2 APPSRTN 1 CANVNT FPC ACPT ACCR MAF MAF MAFRTN IAT FTPT INJPWRM BOO BPS MAFRTN PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT) PWR GND SMART JUNCTION FUSE BOX (SJB) (BASE OF LEFT "A" PILLAR) SMR STARTING/CHARGING SYSTEM TRSW VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
