Lincoln MKZ I (2006-2009) head parklamp off Wiring diagram
This page shows the only wiring diagram for the component.head parklamp off, which is found in the car Lincoln MKZ I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head parklamp off (1 of 1)
BALLAST
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FOG
FOG IND
FOG LAMP RELAY
FRONT FOG COMMAND
FRONT FOG IND FOG LAMPS ON
FTP
FUSE 11
FUSE 19 FUSE 27
FUSE 2
FUSE 23
FUSE 24
FUSE 26
GRN WIRE
GRN/BRN WIRE
GRY WIRE
GRY/ORG WIRE
HEAD PARKLAMP OFF
HI BEAM HID LOW BEAM
HIGH BEAM RELAY
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LATE PRODUCTION EARLY PRODUCTION
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LEFT HIGH INTENSITY DISCHARGE HEADLAMP RELAY
LOGIC
MAIN LIGHT SWITCH
MS CAN +
MULTIFUNCTION SWITCH
OF ENGINE COMPT)
ORG/ WIRE
PARK LAMPS ON LOW BEAM REQ FLASH TO PASS HIGH BEAM REQ
PARK OFF LOW
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
RIGHT HIGH INTENSITY DISCHARGE HEADLAMP RELAY
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Headlights circuit, without autolamps with high intensity gas discharge headlights -> HEAD PARKLAMP OFF
