Lincoln MKZ I (2006-2009) dual automatic temperature control Wiring diagrams
This page contains all the electrical diagrams for the component. dual automatic temperature control, in which he is found in the car Lincoln MKZ I (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dual automatic temperature control (1 of 2)
11 12 MS CAN + MS CAN -
12 13 MS CAN + MS CAN -
12 6 MS CAN+ MS CAN-
14 15 (NOT USED)
15 16 15 16 MS CAN+ MS CAN-
2 1 15 14 MS CAN+ MS CAN- HS CAN+ HS CAN-
6 SPEED TRANSMISSION
ABS CONTROL MODULE (RIGHT FRONT OF ENGINE COMPARTMENT)
ALL WHEEL DRIVE CONTROL MODULE (LEFT KICK PANEL)
AUDIO UNIT (CENTER
B+ DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH)
BASE AUDIO/ AUDIO- PHILE THX AUDIO/ NAVI- GATION
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
DRIVER SEAT MODULE
DRIVER'S DOOR MODULE
DUAL AUTOMATIC TEMPERATURE CONTROL
ELECTRONIC AUTOMATIC TEMPERATURE CONTROL
FEPS
FEPS HS CAN-
FUSE
GRY WIRE
GRY/ORG WIRE
HEATED/COOLED SEAT MODULE (UNDER SEAT BOTTOM) MS CAN-
HOT AT ALL TIMES
HS CAN + HS CAN -
HS CAN+
HS CAN+ HS CAN- HS CAN+
INSTRUMENT CLUSTER
MS CAN +
MS CAN+ PWR GND SIG GND HS CAN+
OCCUPANT CLASSIFICATION SENSOR (OCS) (IN SEAT CUSHION)
OF DASH)
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT REAR OF ENGINE COMPT)
RED WIRE
RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE)
SATELLITE RADIO RECEIVER
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR) MS CAN-
THX AMPLIFIER (WITH THX)
TRANSMISSION
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit, with memory -> DUAL AUTOMATIC TEMPERATURE CONTROL
Wiring diagram dual automatic temperature control (2 of 2)
