Lincoln MKZ I (2006-2009) decklid release solenoid/ ajar switch (fusion/milan: (center rear Wiring diagram
This page shows the only wiring diagram for the component.decklid release solenoid/ ajar switch (fusion/milan: (center rear, which is found in the car Lincoln MKZ I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram decklid release solenoid/ ajar switch (fusion/milan: (center rear (1 of 1)
BATTERY JUNCTION BOX (BJB) (EXCEPT 3.0L: LEFT SIDE OF
BLK/GRY WIRE
BLK/VIO WIRE
BRN WIRE
DECKLID RELEASE RELAY
DECKLID RELEASE SOLENOID/ AJAR SWITCH (FUSION/MILAN: (CENTER REAR
DECKLID RELEASE SWITCH
EARLY PRODUCTION LATE PRODUCTION
FUSE 1
FUSE 16
FUSE 23 2 ENGINE COMPARTMENT) (3.0L: LEFT FRONT OF ENGINE COMPARTMENT)
GRN/WHT WIRE
HOT AT ALL TIMES
ILLUMINATION
LOGIC DECKLID AJAR SW DECKLID RELEASE SW
OF TRUNK)
RED WIRE
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
VIO/GRY WIRE
WHT/RED WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Trunk release circuit -> DECKLID RELEASE SOLENOID/ AJAR SWITCH (FUSION/MILAN: (CENTER REAR
