Lincoln MKZ I (2006-2009) bsi sol cmd Wiring diagram
This page shows the only wiring diagram for the component.bsi sol cmd, which is found in the car Lincoln MKZ I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bsi sol cmd (1 of 1)
6 SPEED TRANSMISSION
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLU WIRE
BRN WIRE
BSI SOL CMD
FLOOR SHIFTER
FUSE 14
FUSE 19
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INHIBIT
LATE PRODUCTION
LED SW BKLGT
O/D
PARK
RED WIRE
SHIFT LOCK SOLENOID
SJB LOGIC
SMART JUNCTION BOX (SJB) (BASE OF LEFT "A" PILLAR)
VIO WIRE
VIO/GRY WIRE
Go to component -> Shift interlock circuit -> BSI SOL CMD
