Lincoln MKZ I (2006-2009) 10 12 6 mem sw ind ms can + ms can - Wiring diagram
This page shows the only wiring diagram for the component.10 12 6 mem sw ind ms can + ms can -, which is found in the car Lincoln MKZ I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 10 12 6 mem sw ind ms can + ms can - (1 of 1)
10 12 6 MEM SW IND MS CAN + MS CAN -
10 3 4 16 12 V BATT MEM SET SW MEM RECALL 1 MEM RECALL 2 GND
AFT
BASE
BLK WIRE
BLK/WHT WIRE
BLU/WHT WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DOWN
DRIVER DOOR MODULE (FRONT OF DRIVER'S DOOR)
DRIVER SEAT LUMBAR MOTOR (IN DRIVER'S SEAT BACK)
DRIVER SIDE FRONT SEAT ADJUST SWITCH
FORE/
FRONT
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INTERIOR LIGHTS
LUMBAR
MEMORY SET SWITCH
OUT
REAR
RECLINE
SYSTEM
TILT DOWN
TILT UP
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Memory seat circuit (2 of 2) -> 10 12 6 MEM SW IND MS CAN + MS CAN -
