Driver"s memory seat circuit, 10-way driver seat for Lincoln MKX II (2015-2018)

AFT BASE BACKWARD BASE FORWARD BATTERY JUNCTION BOX (BJB) BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER FRONT SEAT MODULE (DSM) FORWARD/ FRONT DOWN FRONT UP FUSE 74 FUSE 77 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HALL EFFECT RTN HALL EFFECT SENS HOT AT ALL TIMES INCLINE LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR LEFT FRONT SEAT POWER LUMBAR ASSEMBLY LEFT FRONT SEAT RECLINER MOTOR LEFT FRONT SEAT TILT MOTOR LEFT FRONT SEAT TRACK MOTOR MS CAN + PEDALS FORWARD PEDALS REARWARD PEDALS SENS+ REAR DOWN REAR UP RECLINE STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN TELESCOPIC MOTOR STEERING COLUMN TILT MOTOR STEERING COLUMN) TEL MTR FWD TEL MTR RWD TEL SENS TILT MTR (DN) TILT MTR UP TILT SENS VBATT VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE WHT/BRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE

AFT BLK/BLU WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DBCKBLWCTL DBKSENS DBKTED- DBLWR+ DCSHCBLWCTL DCSHSENS DCSHTED- DEFLATE DOWN DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR) DRIVER DOOR WINDOW CONTROL SWITCH DRIVER FRONT SEAT MODULE (DSM) DSENRT FORE/ FRONT HEIGHT GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE HORIZONTAL ILLUM INCLINE INFLATE LEFT FRONT DOOR LOCK SWITCH LEFT FRONT SEAT CONTROL SWITCH LOCK LUMBAR MEMORY SET SWITCH MS CAN + PBCKBLWCTL PBKSENS PBKTED- PBLWR+ PCSHCBLWCTL PCSHSENS PCSHTED- PEDALS MTR FORWARD PEDALS MTR REARWARD PSENRT REAR DOWN REAR HEIGHT REAR UP RECLINE RTN SEATS SYSTEM SET 1 SET 2 SET 3 UNLOCK VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE
