Wiring diagram w/ start/stop w/o start/stop (1 of 4)
BATTERY JUNCTION BOX (BJB)
BLIS IND
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 23
FUSE 25
FUSE 26
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSIDE DRIVER DOOR)
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SODL)
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MS CAN +
PASSENGER DOOR MODULE (PDM)
PWR LOGIC RLY
RED WIRE
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR)
VBATT
VIO/ORG WIRE
VPWR
W/ START/STOP W/O START/STOP
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> W/ START/STOP W/O START/STOP
Wiring diagram w/ start/stop w/o start/stop (2 of 4)
2.7L TURBO
3.7L
AAT
AJAR
AMBIENT AIR TEMPERATURE (AAT) SENSOR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BODY CONTROL MODULE (BCM)
BRK FLUID
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE (EOP) SENSOR
EOP
FUEL LEVEL SENSOR
FUEL PUMP, SENDER UNIT
FUEL SENDER 1
FUEL SENDER 1 RTN
FUEL SENDER 2
FUEL SENDER 2 RTN
FUSE 13
FUSE 23
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEAD-UP DISPLAY (HUD) MODULE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LF DOOR
LIFTGATE
LOGIC RLY
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
LOW WASHER
LR DOOR
LVL SW
MICRO -
NCA WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PR DOOR
RF DOOR
SIGRTN
VBATT
VIO WIRE
VPWR
VREF
W/ START/STOP W/O START/STOP
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> W/ START/STOP W/O START/STOP
Wiring diagram w/ start/stop w/o start/stop (3 of 4)
AUTO PARK IND (FET)
BATT PWR
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
FAPA SENS LH IN
FAPA SENS RH IN
FIL SENS LH IN
FIR SENS RH IN
FOL SENS LH IN
FOR SENS RH IN
FUSE 3
GRY/ORG WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LEFT FRONT ACTIVE PARK ASSIST SENSOR
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MICRO -
PARK AID IND (FET)
RED WIRE
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
SENS GND
SOLID STATE
VBATT
VIO/GRY WIRE
W/ ACTIVE PARKING ASSIST
W/ START/STOP W/O START/STOP
WHT/BLU WIRE
WHT/BRN WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit (2 of 2) -> W/ START/STOP W/O START/STOP
Wiring diagram w/ start/stop w/o start/stop (4 of 4)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER
FUSE 23
HOT W/ RUN/START RELAY ENERGIZED
LIN 4
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MICRO -
NCA WIRE
PWR LOGIC RLY
REAR PARKING AID CAMERA
SHIELD
SYNC MODULE (APIM)
VIDEO+
VIO/WHT WIRE
VPWR
W/ START/STOP W/O START/STOP
WHT WIRE
WHT/BLU WIRE
Go to component -> Rear camera circuit -> W/ START/STOP W/O START/STOP
