Lincoln MKX II (2015-2018) steering column memory circuit Wiring diagrams
This page contains all the electrical diagrams for the component. steering column memory circuit, in which he is found in the car Lincoln MKX II (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering column memory circuit (1 of 2)
AFT
BASE BACKWARD
BASE FORWARD
BATTERY JUNCTION BOX (BJB)
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT MODULE (DSM)
FORWARD/
FRONT DOWN
FRONT UP
FUSE 74
FUSE 77
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HALL EFFECT RTN
HALL EFFECT SENS
HOT AT ALL TIMES
INCLINE
LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
LEFT FRONT SEAT POWER LUMBAR ASSEMBLY
LEFT FRONT SEAT RECLINER MOTOR
LEFT FRONT SEAT TILT MOTOR
LEFT FRONT SEAT TRACK MOTOR
MS CAN +
PEDALS FORWARD
PEDALS REARWARD
PEDALS SENS+
REAR DOWN
REAR UP
RECLINE
STEERING COLUMN MEMORY CIRCUIT
STEERING COLUMN TELESCOPIC MOTOR
STEERING COLUMN TILT MOTOR
STEERING COLUMN)
TEL MTR FWD
TEL MTR RWD
TEL SENS
TILT MTR (DN)
TILT MTR UP
TILT SENS
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Driver"s memory seat circuit, 10-way driver seat (1 of 2) -> STEERING COLUMN MEMORY CIRCUIT
Wiring diagram steering column memory circuit (2 of 2)
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER RELAY
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DOWN
DRIVER FRONT SEAT MODULE (DSM)
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) (IN DRIVER SEAT BACK)
EXTEND
FUSE 1
FUSE 2
FUSE 53
FUSE 74
FUSE 77
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HALL EFFECT RTN
HALL EFFECT SENS
HOT AT ALL TIMES
LADDER FEED
LADDER RTN
LEFT FRONT MULTI-CONTOUR CONTROL PUMP
LEFT FRONT SEAT CONTROL SWITCH
MICRO -
MS CAN +
MULTI- CONTOUR SEAT RELAY
PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH)
PEDALS FORWARD
PEDALS REARWARD
PEDALS SENS+
PUMP
RETRACT
RTN
STEERING COLUMN MEMORY CIRCUIT
TEL MTR FWD
TEL MTR RWD
TEL SENS
TILT MTR (DN)
TILT MTR UP
TILT SENS
VBATT
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Driver"s memory seat circuit, 16-way driver seat (1 of 2) -> STEERING COLUMN MEMORY CIRCUIT
