Wiring diagram steering column) (1 of 2)
AFT
BASE BACKWARD
BASE FORWARD
BATTERY JUNCTION BOX (BJB)
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SEAT MODULE (DSM)
FORWARD/
FRONT DOWN
FRONT UP
FUSE 74
FUSE 77
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HALL EFFECT RTN
HALL EFFECT SENS
HOT AT ALL TIMES
INCLINE
LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
LEFT FRONT SEAT POWER LUMBAR ASSEMBLY
LEFT FRONT SEAT RECLINER MOTOR
LEFT FRONT SEAT TILT MOTOR
LEFT FRONT SEAT TRACK MOTOR
MS CAN +
PEDALS FORWARD
PEDALS REARWARD
PEDALS SENS+
REAR DOWN
REAR UP
RECLINE
STEERING COLUMN MEMORY CIRCUIT
STEERING COLUMN TELESCOPIC MOTOR
STEERING COLUMN TILT MOTOR
STEERING COLUMN)
TEL MTR FWD
TEL MTR RWD
TEL SENS
TILT MTR (DN)
TILT MTR UP
TILT SENS
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Driver"s memory seat circuit, 10-way driver seat (1 of 2) -> STEERING COLUMN)
Wiring diagram steering column) (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR)
DRIVER DOOR WINDOW CONTROL SWITCH
DRIVER FRONT SEAT MODULE (DSM)
DRIVER'S MEMORY SEAT CIRCUIT
FUSE 74
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HALL EFFECT RTN
HOT AT ALL TIMES
ILLUM
LEFT FRONT DOOR LOCK SWITCH
LOCK
MEMORY SET SWITCH
MS CAN +
RTN
SET 1
SET 2
SET 3
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING COLUMN TELESCOPIC MOTOR
STEERING COLUMN TILT MOTOR
STEERING COLUMN)
TEL MTR FWD
TEL MTR RWD
TEL SENS
TILT MTR DOWN
TILT MTR UP
TILT SENS
UNLOCK
VBATT
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN)
