Lincoln MKX II (2015-2018) shift dn Wiring diagrams
This page contains all the electrical diagrams for the component. shift dn, in which he is found in the car Lincoln MKX II (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shift dn (1 of 3)
2.7L TURBO
3.7L
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
FUSE 26
FUSE 54
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
ISP-R
LPC
MICRO -
OSS +
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
SHIFT DN
SHIFT UP
SIGRTN
SSA
SSB
SSC
SSD
SSE
TCC
TFT
TR 1
TR 2
TR 3
TR 4
TSPC
TSS
TSS/OSS/TR GND
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> A/t circuit (1 of 2) -> SHIFT DN
Wiring diagram shift dn (2 of 3)
AAT
ACPT
AWD-C
BATT MONITOR
BATTERY JUNCTION BOX (BJB)
BLK/YEL WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BPP
BPS
BRN/WHT WIRE
BRN/YEL WIRE
CASEGND
CHARGING SYSTEM
CKCP
COMPUTER
DATA LINES
EOP
FLP
FTP
FUSE 11
FUSE 12
FUSE 26
FUSE 7
FUSE 8
GENRC
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
IAT
NCA WIRE
OPS
PCMRC
POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (PCM) POWER RELAY
PWRGND
SHIFT DN
SHIFT UP
SMCS
STARTING/
STARTING/CHARGING SYSTEM
SYSTEM
TCBP
TCFT
TRANSMISSIONS SYSTEM
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.7l turbo (3 of 9) -> SHIFT DN
Wiring diagram shift dn (3 of 3)
