Lincoln MKX II (2015-2018) pass mirr mtr lt Wiring diagram
This page shows the only wiring diagram for the component.pass mirr mtr lt, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass mirr mtr lt (1 of 1)
BLIS IND
BLK/WHT WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
EXT MIRR POT FEED
FOLD OUT
FOLD-IN
FUSE 25
FUSE 26
GRN/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEDS
LR (-)
MS CAN +
NCA WIRE
PASS HEATED
PASS MIRR HORZ POT
PASS MIRR MTR DN/RT
PASS MIRR MTR LT
PASS MIRR MTR VERT UP
PASS MIRR VERT POT
PASS PUDDLE
PASS TURN
PASSENGER DOOR MODULE (PDM)
PUDDLE
RED WIRE
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
TURN
U/D
VBATT
VIO/ORG WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> PASS MIRR MTR LT
