Lincoln MKX II (2015-2018) liftgate/decklid release ajar Wiring diagram
This page shows the only wiring diagram for the component.liftgate/decklid release ajar, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate/decklid release ajar (1 of 1)
AJAR
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CAN (-) CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE 2
GRN/BLU WIRE
GRN/WHT WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LIFTGATE REL (FET)
LIFTGATE RELEASE
LIFTGATE RELEASE SWITCH
LIFTGATE/DECKLID RELEASE AJAR
LIFTGATE/LUGGAGE COMPARTMENT LID
MICRO -
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Liftgate release circuit -> LIFTGATE/DECKLID RELEASE AJAR
