Lincoln MKX II (2015-2018) left front seat cushion heater mat Wiring diagram
This page shows the only wiring diagram for the component.left front seat cushion heater mat, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front seat cushion heater mat (1 of 1)
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/VIO WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRV HEATER FEED
DRV ST NTC SENSE
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 65
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CUSHION HEATER MAT
MS CAN +
NCA WIRE
PASS HEATER FEED
PASS ST NTC SENSE
RED WIRE
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT FRONT SEAT CUSHION HEATER MAT
SIG RTN
VIO WIRE
VIO/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Front heated seats circuit -> LEFT FRONT SEAT CUSHION HEATER MAT
