Lincoln MKX II (2015-2018) hot w/ ignition relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ ignition relay energized, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ ignition relay energized (1 of 1)
A/D CHANNEL 2
A/D CHANNEL 3
A/D CHANNEL 4
A/D RETURN
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
CANCEL GAP DOWN
CLOCK SPRING (STEERING WHEEL)
COMPUTER DATA LINES SYSTEM
FUSE 23
FUSE 54
FUSE 7
GAP UP
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
HOT W/ POWERTRAIN CONTROL MODULE (PCM) POWER RELAY ENERGIZED
LEDS
LEFT STEERING WHEEL SWITCH
LOGIC GND
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
OFF
POWER DISTRIBUTION SYSTEM
PWR LOGIC RLY
RES+
RES/CANCEL
RIGHT STEERING WHEEL SWITCH
SET-
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING EFFORT CONTROL MODULE (SECM)
VBATT
VPWR
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> HOT W/ IGNITION RELAY ENERGIZED
