Lincoln MKX II (2015-2018) ext mrr pot feed Wiring diagram
This page shows the only wiring diagram for the component.ext mrr pot feed, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ext mrr pot feed (1 of 1)
BLIS IND
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR)
DRIVER DOOR WINDOW CONTROL SWITCH
DRV HEATED
DRV MIRR HORZ POT
DRV MIRR MTR DN/RT
DRV MIRR MTR LEFT
DRV MIRR MTR VERT UP
DRV MIRR VERT POT
DRV PUDDLE
DRV TURN
EXT MRR POT FEED
EXTERIOR REAR VIEW MIRROR SWITCH
FOLD OUT
FOLD-IN
FUSE 23
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
ILLUM
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT FRONT DOOR LOCK CONTROL SWITCH
LEFT REAR DOOR MODULE (RDM)
LIN BUS
LOCK
LR (-)
MEMORY SET SWITCH
MIRRORS SYSTEM
MS CAN +
NCA WIRE
PUDDLE
RED WIRE
RTN
SET 1
SET 2
SET 3
TURN
U/D
UNLOCK
VBATT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> EXT MRR POT FEED
