Lincoln MKX II (2015-2018) drv steering column rtn Wiring diagram
This page shows the only wiring diagram for the component.drv steering column rtn, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv steering column rtn (1 of 1)
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
CASE GROUND
COLLAPSIBLE STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
DRIVER KNEE AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRONT CURTAIN SENS FEED
DRV FRONT CURTAIN SENS RTN
DRV STEERING COLUMN FEED
DRV STEERING COLUMN RTN
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT SEVERITY IMPACT SENSOR
NCA WIRE
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS AIR BAG VENT FEED
PASS AIR BAG VENT RTN
PASS FRONT CURTAIN SENS FEED
PASS FRONT CURTAIN SENS RTN
PASS STEERING COLUMN FEED
PASS STEERING COLUMN RTN
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT SEVERITY IMPACT SENSOR
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
STEERING COLUMN FEED
STEERING COLUMN RTN
VENT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> DRV STEERING COLUMN RTN
