Lincoln MKX II (2015-2018) double/ aux lock relay Wiring diagrams
This page contains all the electrical diagrams for the component. double/ aux lock relay, in which he is found in the car Lincoln MKX II (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram double/ aux lock relay (1 of 2)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
CENTRAL LOCK RELAY
CENTRAL UNLOCK RELAY
CHILD LOCK RELAY
DECKLID/ LIFTGATE RELAY
DOUBLE/ AUX LOCK RELAY
DRIVER DOOR MODULE (DDM)
DRIVER FRONT SEAT MODULE (DSM)
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
DRIVER SAFETY BELT BUCKLE
DRIVER/ FUEL FLAP UNLOCK RELAY
FUEL PUMP CONTROL MODULE
FUEL PUMP CONTROL MODULE SHIELD
FUEL PUMP, SENDER UNIT SHIELD
GRN WIRE
GRY WIRE
HIGH MOUNTED STOP LAMP
KEYLESS ENTRY KEYPAD
LEFT EXTERIOR MIRROR
LEFT FRONT DOOR LOCK INDICATOR
LEFT FRONT DOOR TWEETER SPEAKER
LEFT FRONT MULTI-CONTOUR CONTROL PUMP
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CONTROL SWITCH
LEFT LUGGAGE COMPARTMENT LAMP
LEFT POWER FOLD SEAT MOTOR
LEFT REAR DOOR LOCK INDICATOR
LEFT REAR DOOR MODULE (RDM)
LEFT REAR DOOR TWEETER SPEAKER
LEFT REAR SEAT BACKREST HEATER MAT
LEFT SCUFF PLATE LAMP
LEFT SEAT POSITION SENSOR
LEFT SECOND ROW SAFETY BELT BUCKLE SWITCH
LIFT GATE CARGO LAMP
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
NCA WIRE
ORG/ WIRE
REAR AUDIO CONTROL MODULE (RACM)
REAR HEATED SEAT MODULE
REAR LAMP FADE CONTROL MODULE
REAR WINDOW WIPER MOTOR
REVERSING LAMP
ROOF OPENING PANEL MODULE
W/ AMBIENT LIGHTING
W/ HARMAN REVEL ULTIMA AUDIO SYSTEM
W/ HEATED SEATS
W/ REAR HEATED SEATS
W/ START/ STOP
W/O TOUCH SCREEN, ULTIMA W/O TOUCH SCREEN W/ ULTIMA
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> DOUBLE/ AUX LOCK RELAY
Wiring diagram double/ aux lock relay (2 of 2)
