Lincoln MKX II (2015-2018) circuit breaker 38 Wiring diagram
This page shows the only wiring diagram for the component.circuit breaker 38, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram circuit breaker 38 (1 of 1)
ACCESSORY DELAY RELAY
AMBIENT LTG (FET)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER RELAY
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CENTRAL LOCK RELAY
CENTRAL UNLOCK RELAY
CHILD LOCK RELAY
CIRCUIT BREAKER 38
CLOCK SPRING/ STEERING ANGLE SENSOR MODULE (SASM)
DATA LINK CONNECTOR (DLC)
DECKLID/ LIFTGATE RELAY
DOUBLE/ AUX LOCK RELAY
DRIVER DOOR WINDOW CONTROL SWITCH
DRIVER/ FUEL FLAP UNLOCK RELAY
EARLY PRODUCTION
FROM BSI (FET) (DIAGRAM 2 OF 7)
FROM FUSE 10 (DIAGRAM 4 OF 7)
FUEL PUMP ON (FET)
FUSE 1
FUSE 15
FUSE 16
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 3
FUSE 34
FUSE 35
FUSE 36
FUSE 37
FUSE 8
GLOVE COMPARTMENT LAMP
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE
HEATED STEERING WHEEL MODULE (HSWM) (IF EQUIPPED)
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
KEYPAD ILLUM (FET)
LATE PRODUCTION
LEFT REAR INTERIOR LAMP
LEFT VANITY MIRROR LAMP
LIFT GATE REL (FET)
MICRO -
MULTI- CONTOUR SEAT RELAY
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
ORG/ WIRE
OVERHEAD CONSOLE
REAR HEATED SEAT MODULE
RED WIRE
RESTRAINTS CONTROL MODULE (RCM)
RIGHT REAR INTERIOR LAMP
RIGHT VANITY MIRROR LAMP
ROOF OPENING PANEL MODULE
RUN/START RELAY
SECOND ROW INTERIOR LAMP
SECURITY HORN RELAY
TO DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER (DIAGRAM 7 OF 7)
TO START BUTTON (FET) (DIAGRAM 7 OF 7)
VEHICLE DYNAMICS MODULE (VDM)
VIO WIRE
W/ ADAPTIVE STEERING
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (5 of 7) -> CIRCUIT BREAKER 38
