Lincoln MKX II (2015-2018) camera windshield defrost heater Wiring diagram
This page shows the only wiring diagram for the component.camera windshield defrost heater, which is found in the car Lincoln MKX II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera windshield defrost heater (1 of 1)
AUTO DIMMING INTERIOR MIRROR
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
CAMERA WINDSHIELD DEFROST HEATER
CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE 36
GRN/ORG WIRE
GRY/BLU WIRE
HEATER
HOT W/ RUN/START RELAY ENERGIZED
LEFT EXTERIOR MIRROR
NCA WIRE
PROXIMITY WARNING RADAR UNIT
VIO/WHT WIRE
VPWR
W/ ADAPTIVE CRUISE
Go to component -> Electrochromic mirror circuit, w/ automatic wiper -> CAMERA WINDSHIELD DEFROST HEATER
