Lincoln MKX I facelift (2010-2015) Adaptive front lighting circuit

BATTERY JUNCTION BLK/GRN WIRE BLU/GRN WIRE BLU/GRY WIRE COMPUTER DATA LINES SYSTEM FUSE 89 BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GND SENS GND GRN/BRN WIRE GRN/VIO WIRE GRY/VIO WIRE HEADLAMP CONTROL MODULE (HCM) LEFT HEADLAMP HOT IN START OR RUN HS CAN+ ISP-R SENS SIG VCC HS CAN + RIGHT HEADLAMP SENS GND SENS SIG VCC STEERING COLUMN CONTROL MODULE (SCCM) (STEERING COLUMN) VIO/GRY WIRE WHT WIRE WHT/BLU WIRE YEL/GRY WIRE
