Lincoln MKX I facelift (2010-2015) st input lr- Wiring diagram
This page shows the only wiring diagram for the component.st input lr-, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram st input lr- (1 of 1)
2.0L
ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (CENTER OF DASH)
AUDIO INPUT JACK
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
EXCEPT 2.0L
GRY/ORG WIRE
GRY/RED WIRE
HS CAN+ HS CAN- USB
I CAN -
MIC -
MICROPHONE (CENTER FRONT OF ROOF)
NAVIGATION SYSTEM
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT)
PWR GND PWR GND
REAR CAMERA+ REAR CAMERA- I CAN+ I CAN-
SHIELD
SHIELD SHIELD STEREO R + STEREO R - STEREO L + STEREO L -
SMCS
ST INPUT LR-
STARTER RELAY
STEREO LR-
STEREO SHIELD
SYNC ALERT+ SYNC ALERT- MIC+ MIC-
USB
USB CABLE
USB PORT
VBATT
VIDEO+
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/GRN WIRE
Go to component -> Sync radio circuit, with sync gen 1 (1 of 2) -> ST INPUT LR-
