Lincoln MKX I facelift (2010-2015) right vanity mirror lamp overhead console Wiring diagram
This page shows the only wiring diagram for the component.right vanity mirror lamp overhead console, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right vanity mirror lamp overhead console (1 of 1)
AUDIO AMPLIFIER (MKX W/ PREMIUM AUDIO)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE (EDGE W/ SONY AUDIO)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE (MKX W/ THX AUDIO)
BATTERY SAVER RELAY
BLU WIRE
BRN WIRE
CENTER INTERIOR LAMPS
DRIVER SIDE FRONT POWER WINDOW MOTOR
FROM FUSE 21 (DIAGRAM FUSE 7 4 OF 7)
FROM FUSE 24 (DIAGRAM FUSE 27 3 OF 7)
FROM PARK LAMP RELAY (DIAGRAM 4 OF 7)
FRONT LIGHTING CONTROL MODULE (FLM)
FUSE 1
FUSE 19
FUSE 2
FUSE 21
FUSE 23
FUSE 3
FUSE 4
FUSE 40
FUSE 5
FUSE 6 FUSE 8
GLOVE BOX LAMP (MKX)
GRN WIRE
GRY WIRE
LEFT REAR LAMP ASSEMBLY
LEFT VANITY MIRROR LAMP
MICRO -
NCA WIRE
PARK LAMP RELAY
PASSENGER SIDE FRONT POWER WINDOW MOTOR (MKX)
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT LEFT LICENSE LICENSE PLATE PLATE LAMP LAMP (MKX) (MKX)
RIGHT REAR LICENSE LAMP LAMP ASSEMBLY (EDGE)
RIGHT VANITY MIRROR LAMP OVERHEAD CONSOLE
STEERING COLUMN CONTROL MODULE (SCCM)
SUBWOOFER AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE
TIRE PRESSURE MONITOR (TPM) MODULE
TO ACCESSORY DELAY RELAY (DIAGRAM 5 OF 7)
TO FUSE 4 (DIAGRAM FUSE 30 4 OF 7)
TO FUSE 7 (DIAGRAM 4 OF 7)
TO SPLICE 109 (DIAGRAM 6 OF 7)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (4 of 7) -> RIGHT VANITY MIRROR LAMP OVERHEAD CONSOLE
