Lincoln MKX I facelift (2010-2015) pinch rtn chime+ Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 GND CINCH BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE BRN WIRE BRN/BLU WIRE CHIME- MS CAN+ MS CAN- CINCH MOTOR CLOSE SW CLUTCH CLUTCH VBATT COMPUTER DATA LINES SYSTEM FUSE 7 FUSE 9 GEAR GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE LATCH SW FULL LATCH SW HALF LATCH SW HALF SENSOR PWR LEFT LIFTGATE PINCH STRIP (LEFT SIDE OF LIFTGATE) LH PINCH STRIP LIFTGATE LATCH/UNLATCH ASSEMBLY (LOWER CENTER OF LIFTGATE) LIFTGATE MOTOR/CLUTCH (LEFT "D" PILLAR) LIFTGATE REAR CONTROL SWITCH LIFTGATE RELEASE LIFTGATE RELEASE CIRCUIT LIFTGATE RELEASE RELAY LIFTGATE/TRUNK MODULE (LTM) (BASE OF LEFT "D" PILLAR) MICRO - NCA WIRE ORG/ WIRE PILLAR) PINCH RTN CHIME+ POSITION SENSOR POWER LIFTGATE CHIME (BASE OF LEFT "D" PILLAR) POWER LIFTGATE RELEASE SWITCH RATCHET SW REAR WINDOW DEFROST (LEFT GRID "D" PILLAR) RED WIRE REMOTE FUNCTION ACTUATOR (REA) MODULE (BEHIND GLOVE BOX) RIGHT LIFTGATE PINCH STRIP (RIGHT SIDE OF LIFTGATE) SENSOR RTN CONSOLE OPEN/ SW 1 SW 2 UNCINCH VBATT MOTOR OPEN MOTOR CLOSE VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE W/ INTELLIGENT ACCESS W/O INTELLIGENT ACCESS WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
