Lincoln MKX I facelift (2010-2015) mirror select Wiring diagram
This page shows the only wiring diagram for the component.mirror select, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror select (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
DEFOGGER SYSTEM
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
INTERIOR
LEFT RIGHT
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LIGHTS SYSTEM
MIRROR SELECT
NAVIGATION SYSTEM
NCA WIRE
RED WIRE
RIGHT LEFT
RIGHT SIDE EXTERIOR REAR VIEW MIRROR
UP DOWN
VIO WIRE
W/ POWER SEATS
WHT WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> MIRROR SELECT
