Lincoln MKX I facelift (2010-2015) in vehicle sig lf temp sns Wiring diagram

2.0L 3.5L/3.7L BLK WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE DATC HVAC MODULE EVAPORATOR TEMPERATURE SENSOR (LEFT SIDE OF HVAC UNIT) FUSE 37 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES BODY CONTROL MODULE (BCM) FUSE 46 (LEFT KICK PANEL) HOT IN HUMIDITY IN VEHICLE SIG LF TEMP SNS IN VEHICLE TEMPERATURE SENSOR (W/ DUAL ZONE) (LEFT SIDE OF DASH) IN-VEHICLE TEMPERATURE/HUMIDITY SENSOR (2.0L) (LEFT SIDE OF DASH) LED RETURN NCA WIRE OR RUN ORG/ WIRE PASS SUNLOAD DR SUNLOAD RED WIRE SEATS SYSTEM 3.5L/3.7L SOLID STATE VIO WIRE VIO/BRN WIRE VIO/GRY WIRE W/ AMBIENT LIGHTING WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE
