Lincoln MKX I facelift (2010-2015) hazard switch 1 2 3 4 5 6 vbatt ican+ ican- haz sw computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.hazard switch 1 2 3 4 5 6 vbatt ican+ ican- haz sw computer data lines system, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard switch 1 2 3 4 5 6 vbatt ican+ ican- haz sw computer data lines system (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL) FUSE FUSE
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
FUSE
FUSE 47
FUSE FUSE
GND (LEFT SIDE FRONT CONTROL OF DASH) INTERFACE MODULE (FCIM) (CENTER OF DASH)
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HAZARD SWITCH 1 2 3 4 5 6 VBATT ICAN+ ICAN- HAZ SW COMPUTER DATA LINES SYSTEM
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT FRONT PARK/TURN LAMP
LEFT HEADLAMP SIDE MKR LEDS
LEFT LICENSE PLATE LAMP
LEFT SIDE RIGHT SIDE EXTERIOR EXTERIOR REAR VIEW MIRROR REAR VIEW MIRROR
LF TURN LAMP (FET)
LH CORNER LAMP (FET)
LR STOP/ TURN LAMP (FET)
MICRO -
PARK
REVERSE LAMP (FET)
RF TURN LAMP (FET)
RH CORNER LAMP (FET)
RIGHT FRONT PARK/TURN LAMP
RIGHT HEADLAMP
RIGHT LICENSE PLATE LAMP
RR STOP/ TURN LAMP (FET)
SIDE MKR LEDS
STOP/ CHMSL (FET)
TRAILER ADAPTER CIRCUIT
TURN SIGNAL
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WIRING HARNESS, NEAR BREAKOUT
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HAZARD SWITCH 1 2 3 4 5 6 VBATT ICAN+ ICAN- HAZ SW COMPUTER DATA LINES SYSTEM
