Lincoln MKX I facelift (2010-2015) handle pull Wiring diagram
This page shows the only wiring diagram for the component.handle pull, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram handle pull (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU/GRY WIRE
DOOR PULL RELEASE HANDLE HANDLE
DOOR RELEASE HANDLE
GRY/ORG WIRE
HANDLE PULL
HANDLE RELEASE DOOR
HANDLE)
LED BLUE
LED GREEN
LED RED WIRE
LED WHITE
LEFT FRONT DOOR LED
LEFT REAR DOOR LED
MAP
MAP POCKET
PIGTAIL HARNESS
POCKET
POCKET MAP
PULL
PULL HANDLE
RIGHT FRONT DOOR LED
RIGHT REAR DOOR LED
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> HANDLE PULL
